AREMA rail joint bar used in north america
Steel Rail and Rail Joint Bar used in North America
While the design of ancillary structures for the railway environment may introduce considerations not found in their non-railway counterparts, these considerations are usually well defined in the governing railway.s standards. Accordingly, this chapter will focus primarily on track carrying structures.
In non-railway counterparts, special considerations shall be considered on rail fastener parts which are needed, it is usually specified in railway standards. In America and Canada, AREMA 2007 and AREMA 2010 are most used steel rail standards, which means the rail joint bar- fishplate is also defined by steel rails that are used for railway line.
Here are the specifications of popular grades of rail joint bars:
AREMA Standard Rail Joint Bar Grades
| Joint Bar For AREMA 2007/2010 Standard Steel Rail | |||
|---|---|---|---|
| Model Number | Standard | Material | Hole Diameter |
| 100RB | AREMA 2007 | Steel Grade55# | 1-3/16'' |
| 100RB-8 | 1 1/8'' | ||
| 100RB-25 | ? | ||
| Special 115RE | 1-3/16'' | ||
| Isolated 115RE | 1-3/16'' | ||
| 115-119RE | ? | ||
| Isolated 132RE | 1-5/16'' | ||
| 132-136RE | ? | ||
| 132lb. RE | 1-5/16'' | ||
| 136lb. RE | 1-5/16'' | ||
| 140LB AREA | AREMA 2010 | Steel Grade55# | ? |
| 152LB PS | ? | ||
| 155LB PS | ? | ||
AREMA Rail Joint Bar for Crane Rail
| Fish Plate/Joint Bar For Crane Rail | ||||
|---|---|---|---|---|
| 104LB.CR | AREMA 2007 | 1.0625 | ||
| 105LB.CR | 1.3125 | |||
| 135LB.CR | 1.1875 | |||
| 171LB.CR | 1.1875 | |||
| 175LB.CR | 1.1875 | |||
